This CNCGLASS lamination guide sets out the handling, lay-up and process conditions recommended for CNCGLASS ionoplast interlayer film in laminated safety and architectural glass, from goods-in to the finished laminate. It is written for laminating plants and assumes a roller press, or a vacuum bag with an autoclave, tempered or annealed glass, and a clean lay-up room. The film is an ethylene–methacrylic acid ionomer copolymer carrying about 1 % by mass of sodium ions; that ionic phase is what separates it from a plasticised PVB interlayer. It is supplied clear, in roll or sheet form, at thicknesses of 0.76, 0.89, 1.14, 1.35 and 1.52 mm, in a roll width of 2,400 mm and lengths of up to 100 m per roll, packed in a vacuum moisture-barrier bag, with 1.52 mm also supplied as cut sheets. Typical applications include structural glazing, facades, balustrades and stairs, open-edge laminates, canopies, floors, point-supported and sloped or overhead glazing, and security or blast-resistant assemblies. The document states that the process windows quoted are starting points, not a specification, that the first production run of any new build-up should be a controlled trial — boil test and visual check — before the batch is released, and that this is a CNCGLASS lamination guide setting out process practice and typical properties; it is not a product warranty, and it does not replace a first-off trial on the equipment that will run the work.
Three conditions are stated before the first panel is run: film moisture at or below 0.2 %, the tin face confirmed on both panes, and a clean lay-up room at or below 25 °C and 30 % RH. Typical laboratory values for the film as supplied — described as typical figures, not guaranteed limits for any single roll — include a specific gravity of 0.93–0.98 g/cm³, tensile strength of ≥ 30 MPa, tear strength of 50 MJ/m², elongation at break of ≥ 300 %, Shore D hardness of 65 on a 12.5 mm stack, a melting point of 94 °C, a yellowness index of < 1.5, a refractive index of 1.5 at 20 °C, light transmittance of 90.2 % and haze of < 1.5 % at 0.76 mm, and UV blocking of > 99 % at the 380 nm peak. Moisture is identified as the variable that can spoil an ionomer laminate silently: store the film in the sealed bag at 25 °C or below and 30 % RH or below; unopened rolls keep for two years at ordinary warehouse temperature; reject film above 0.2 % moisture determined by the loss-on-drying method; and reseal after every opening.
Lay-up is specified as air / tin / film / tin / air, with the film cleaned by an adhesive roller immediately before lay-up, surplus film trimmed only after a cooling interval, and deionised wash water used where available. For the roller-press route with one film ply, the reference sequence is a 150 °C preheat entry zone, a second nip at 60 ± 3 °C exit with a nip gap 1–2 mm less than the nominal glass thickness, and an autoclave hold of not less than 130 °C for not less than 80 min at 12–14 bar, with vent temperature not above 42 °C. Reference roller-press parameters at 1.52 mm film are given for 6, 8, 10 and 12 mm glass build-ups. Three or more plies, or two film layers, are not roller-pressed; they are pre-rolled without completing the edge seal, bagged, and drawn under a cold vacuum. When the film faces a non-tin surface, an adhesion promoter is mandatory; two silane reference formulations are given, and excess promoter is stated to reduce bond strength rather than improve it. Coated glass — frit, solar-control, Low-E — needs a compatibility and adhesion trial before production. The guide also covers diagnosis and correction of five common defects, including delamination and boil-test failure, edge shrink-back, high haze, inclusions and local iridescence.
Contact for this work is Peter Lin at CNC Ucolin Interlayer Technology Co., Ltd. (brand CNCGLASS), SHENZHEN, GD, CHINA, email cnc@cncglass.com.
